CUBE10 PRO
TECHNICAL PARAMETERS
| Items | Camber | TOE | Caster | Kingpin(S.A.I.) | I.A | Setback | Thrust Angle | Wheel Offset | Axle Offset |
|---|---|---|---|---|---|---|---|---|---|
| Range | ±45° | ±30° | ±45° | ±45° | ±45° | ±20° | ±30° | — | — |
| Accuracy | ±1' | ±1' | ±1' | ±1' | ±1' | ±1' | ±1' | ±1mm | ±1mm |
| Operating Temperature | -30~50°C |
| Power Requirement | 100~120V(1Ph, 50~60Hz) 190~240V(1Ph, 50~60Hz) |
| Power Consumption | 300~350W |
| Size of Target | Front:139×139mm Rear:185x185mm |
| Tire Diameter | 457.2~1104.9mm |
| Track Width | 1220~2450mm |
| Wheelbase | 1600~5600mm |
| Rolling Compensation Style | Backward / Forward |
| Camera Resolution | 3096*2080 Single Camera(6.4M x2) |
| Distance from Camera to Turnplate | 1.5m ~ 3m |
Touchless wheel clamps are suitable for more than 95% cars and no metal-to-metal contact, avoid damaging the rim.
Available to pass "suspension clamping test" or "off-center clamp test". No fear of deformation of clamp, target and rim. Low operation requirements, long service life.
Capture data more accurately without the interference of strong ambient light, and say goodbye to the embarrassment of closed-door positioning.
Measure in a low position and adjust in a high position, people and vehicles are safe.
Easy to quickly and accurately measure toe angle, even on older vehicles, helping you increase customer coverage, solve the toe problems of special car models.
Provide corresponding data for the chassis deformation of the accident vehicle to increase profits, offers one-stop service for accident vehicles.
Helps you know the status in real time without repeated pushing measurement or assistance from others, just need one time run out pushing.
Support for adjustment of more special models, improve service competitiveness and car coverage, beneficial to increase more potential customers.
